Multicore wire 1x1.5 H05V-K Royan
Royan
Iran
The sprinkler wires are soft because they consist of a large number of thin twisted copper wires and have high flexibility and are therefore used in building wiring.The rated voltage of these sprinkler wires is 500 /. It is 300 volts and available at different cross-sections according to the passing current.
You can also make a price as a seller
Request a price to negotiate and get a better offer
Suppliers
| Suppliers | Expiration date | Price (Toman) | Minimum order (MOQ) | City | Phone number |
|---|---|---|---|---|---|
The price is not recorded | |||||
similar products
Multicore wire 1x1.5 H05V-K Royan
This embedded wiring harnesses the ISIRI 607 02 standard and a standard H05V-K electrical wiring harness with 32 anode 0.24 mm diameter annealed copper conductors, suitable for installation inside electrical appliances and lighting systems. Sold in the market for electrical and electronic equipment and having a cross section of 1.5 mm2, rated voltage of 450/750V and PVC insulation of 3mm diameter, it can be used in dry environments, inside pipes and under And used plaster for cabling.
ویژگی های کلی
Standard
ISIRI 607 02
Type
Conventional wire spreader (H05V-K)
Rated voltage (V)
450-750
Hadi
Annealed copper Group 5
Insulation
PVC
Cross section (mm ^ 2)
1.5
Insulation thickness (mm)
3
Number of conductors
32
Conductor diameter (mm)
0.24
