Rotating partition balcony glass PMG80 Aria Shishe Motaharek Pars

Rotating partition balcony glass PMG80 Aria Shishe Motaharek Pars

Aria Shishe Motaharek Pars

437/5000
The use of this model is recommended in the entrances of shops, shops and shopping centers, office and office partitions, terrace entrances, parking lots and movable decorative walls inside houses and special glass and wood rooms. Unlike other models, which have special profiles for moving the glass both on the floor and on the roof of the installation site, in PMG80 models no profile is installed on the floor and the whole movable system is restrained from the roof of the structure using special profiles and fittings. May be.
You can also make a price as a seller
Request a price to negotiate and get a better offer

Suppliers

SuppliersExpiration datePrice (Toman)Minimum order (MOQ)CityPhone number
The price is not recorded

Rotating partition balcony glass PMG80 Aria Shishe Motaharek Pars

Due to the high weight of the profiles, fittings and glass used, the system often needs its own ironwork. The material and cross section of the load-bearing profile attached to the roof are completely special and due to the use of completely special fittings, it is possible to use this system in any place. Also, removing the floor profile facilitates the passage of people, equipment and machine. It becomes a tool, because when the windows are open, there are no physical obstacles, such as profiles or anything else, on the floor, and the floor of the door will be the same as before the installation of the mechanism. The important point in this model is that the glasses are not connected to each other and move completely independently of each other, which allows the user to open any desired part of the port. There is a special lock on each piece of glass, according to the special type of sliding mechanisms used in this system, each of these mechanisms alone can carry 150 kg of load, the possibility of installing wooden sheets or from MDF is available on the glass panels used, in which case it is possible to use this system as a movable wall.

ویژگی های کلی

Frame profile width (cm)
6
Frame profile height (cm)
7
Thickness of the frame profile used on the roof (mm)
6.5
Glass profile height (cm)
7
Maximum allowable system height (cm)
400
Maximum width of glass (cm)
100
Plating thickness on profiles (μ)
15
Max bearing weight for roof mounted profiles (kg)
1500 kg per 6 m in length
Usable places
Ports with smooth shapes
Securite glass thickness (mm)
10
