MTOBOND2200 sealing concrete adhesive Clinic Beton Iran

Basic expenses

concrete repair
Mortar or final floor covering
External coating
Sealing and tank construction
Installing bricks and tiles on sloping surfaces
Steel protector against rust

applications
Concrete repair:

Damaged concrete, repair of floors, slabs and prefabricated concrete parts.

Floor mortar and final coating:

Wear resistance and dust-free surface, intermediate layer for special facades, medium resistance to chemicals and preventing layer separation.

External coating:

Waterproof coating and resistant to atmospheric and freezing factors.

Sealing and tank construction:

Sealing foundations, elevator pits, inspection rooms, water towers, liquid tanks, small pools and water tanks.

other things:

Installation of tiles, installation and adjustment of bricks on sloping surfaces, bonding of new and old concrete.

Points

Premature hardening
Improve flexibility
Noticeable reduction in shrinkage
Prevent spillage
Reducing the ratio of water to cement
Increased durability and hardness
High resistance to water penetration
Good wear resistance
Good stability against freezing and penetration of salts
Good resistance to many chemicals and mineral oils Adhesion to concrete and steel Good adhesion to brick, glass, asphalt, wood, expanded polystyrene and most building materials.
Long-lasting corrosion protection Proven thermal and expansion properties identical to concrete (unlike resin mortars and primers)
It is non-toxic. It can also be used in drinking water tanks.
Economical level of epoxy and polyester mortars.

Function

The use of flexible latex in cement mortars and grouts compensates for many of the shortcomings of the mixing plan, without causing any loss in its characteristics and resistances. MTOBOND2200 is specially designed for Portland cements. When the cement mortar dries, the remaining holes in it cause weakness and water leakage. The presence of MTOBOND2200 in these mortars causes the resin particles to join each other and form multiple layers. The resulting fibers sew together the edges of the holes and block them, as a result, the stability of the mortar against water penetration increases. Composition
MTOBOND2200 and cement create excellent adhesion. Both products complement each other's features.

Compounds

MTOBOND2200 is a milky white product obtained from the combination of special polymers. This latex consists of microscopic rubber particles dissolved in liquid. MTOBOND2200 modified compounds may be slightly darker than the modified mixture.

packing

MTOBOND2200 is available in 3.5, 8 and 20 liter containers.

Attributes

The following features are based on a 3 to 1 sand and cement mix and for mixing 10 liters of MTOBOND2200 with 50 kilos of cement.

Compressive strength: 40 MPa depending on the type of cement and mortar performance.
The stability against freeze and thaw cycles is excellent.
Water vapor penetration: less than 4 grams per square meter in 24 hours through a piece with a thickness of 11 mm.
Adhesion: Excellent to concrete, steel, brick, glass, etc.
Chemical stability: It is stable against mild solutions of acids, alkalis, sulfates, chlorides, urea, fertilizer, lactic acid, sugars, etc.
Excellent resistance to water pressure up to 30 meters
is.

The above flux resistance is true in a special design and may differ with the change of cement and efficiency.

MTOBOND consumption is 2200 liters for 50 kg of cement.

standards

Water Research Institute has approved this product for use in drinking water structures.

directions

Surface preparation

The surfaces on which MTOBOND2200 is used must be clean, hard and free from harmful substances. Clean all the cement leachate, oil, grease and curing agent with the help of a wire brush, floor cleaner or any other mechanical device. The existing steels should also be clean and free of oil and grease and remove any kind of dirt and rust. When repairing chipped and damaged concrete, make sure to cut to the hard part of the concrete.

Bonding grout:

Soak absorbent surfaces such as concrete, brick and stone, make sure that these substrates are saturated but there is no surface water. The binder slurry using 1.5 to 2 cups of cement and a cup
Prepare MTOBOND2200 and stir until the solution is uniform. With the help of a stiff brush, apply the grout on the wet surface so that the needle holes on the surface are no longer visible, do not pour the grout with a thickness of more than 2 mm on the surface. If it is necessary to apply the second layer, the surface of the first layer must be dry.
The second layer is in the same direction as the first layer, using 20 liters of MTOBOND2200 mixed with 50 kg of Portland cement type 1 to form a creamy slurry that is usually enough to cover 20 square meters of surface.
Ingredients for modified mixing scheme with MTOBOND2200

sand

The sand must be broken and settled. have regular granulation and no extra fine grain, follow BS-C882 standard for general use and BS-1192 for coating.

Cement

MTOBOND2200 is compatible with all types of Portland cements and sulfate-resistant cement types 2 and 5. For the use of other cements, contact Iran's concrete clinic office.

Water

The strong lubrication properties of MTOBOND2200 reduce the water-to-cement ratio with any performance.

MTOBOND2200, its standard consumption amount is 5 liters per 50 kilos of cement. For other needs such as: exposure to chemicals or depreciation, up to 10 liters for 50 kilos of cement is also recommended.

mixing

It is better to do the mixing in a concrete mixer properly, if there is a mixer, it is recommended to use it. Manual mixing is allowed only when the total weight of the mixture does not exceed 25 kg. Pour the required amount of sand and cement into the mixer and mix

Mix for a minute. Add MTOBOND 2200 and mix for only two minutes to prevent excess air. Finally, slowly add water without delay until the desired concentration is obtained. Due to the lubricating property of MTOBOND2200, the mixture may be extremely diluted, so avoid pouring excess water.

Instructions for implementation
Plating of vertical surfaces:

Apply the bonding grout on the prepared surfaces and then apply MTOBOND2200 coating on the wet grout. Apply MTOBOND2200 modified mortar in layers with a maximum thickness of 6 mm in each hand. Thickening the layer may cause it to spill. Use multiple layers to reach the desired thickness and allow 15 to 30 minutes for the next layer. Smooth the final surface with a metal trowel or trowel board. Another method is to give it a day to dry after applying the first layer, then apply a layer of grout and the second layer.

Application of mortar or final layer on horizontal surfaces

Mortar modified with MTOBOND2200 can be poured to different thicknesses from 6 to 60 mm in one step. After mixing, pour MTOBOND2200 modified mortar on the freshly primed surface. Then squeeze it completely and smooth it. In the last step, you can use a metal trowel or a trowel to smooth its surface according to the desired conditions.

Attention

When mortar is poured on existing concrete surfaces. It is important that the existing expansion joints of the concrete continue in the modified mortar. For this purpose, thin boards wrapped in a polyethylene sheet can be used and placed inside the expansion joints.

processing

The processing of cement mixtures combined with MTOBOND2200 is important. Moisture curing is necessary for the first 24 hours to complete the hydration of the cement, and then allow it to dry slowly because the latex filler particles must bond together to form thin, continuous layers.

important things

Never apply concrete or mortar containing MTOBOND2200 over dried bonding mortar.
Always use fresh, cooled cement with clean, well-graded crushed stone aggregates that are free of extra fines.
Shorten the mixing time and follow the instructions.

Mixes containing MTOBOND2200 may seem deceptive at first because they appear drier than usual. But it is easily compressed and can be troweled. So avoid drinking too much water.

Troweling should be done only as needed. Avoid additional troweling or repeating it. Meanwhile, protect the mortar so that it does not dry before troweling.

Care of work equipment

Clean tools with water immediately after use. In case of delay, using soap and dishwashing wire is very effective. Petroleum solvents can be used to clean the dried pieces of mortar.

Consumption amounts

For general and standard use, 5 liters of MTOBOND2200 is enough for 50 kilos of cement. In difficult conditions or when goals such as adhesion, sealing, steam resistance or chemical resistance are considered, the amount of consumption increases up to 10 liters for 50 kilos of cement. In this range, there is no need to use additional water, and sometimes the use of wet aggregates causes additional efficiency.

compatibility

MTOBOND2200 is specifically designed for use with Portland cements, it is also compatible with type 2 and 5 sulfate resistant cements. Lime (more than 10% of cement weight), aerating agent and masonry cement should not be used with MTOBOND 2200.

The effect of excess consumption

Recommended consumption amounts should not be increased. Additional consumption is not acceptable even in terms of acceptable performance because it increases the polymer ratio and thus reduces the compressive strength
will be

Material specifications

All the above-mentioned basic designs must be modified with MTOBOND2200, a product of Iran Concrete Clinic, or similar approved products that have the following specifications:

Ingredients: milky white latex specially made for Portland cements.
Alkalinity: 5/10
Specific weight: 1.01
Average particle size: 0.17 microns
Butadiene content: 40% by weight of MTOBOND2200

inventory

Store in a covered place away from sunlight and high temperatures. Failure to comply with the suggested storage conditions may damage the product or its container.

safety tips

Avoid contact with eyes or skin. Always use gloves and appropriate clothing when working. In case of possible contact with the eyes, immediately wash with clean water for 15 minutes. In case of skin contact, clean it with soap and water. It is recommended to use the doctor's instructions.
