Body:
The base and chassis of the machine is very thick galvanized steel, which is riveted by stainless steel. The whole body is painted with RAL 7035 coating.
Compressor:
These compressors are equipped with anti-vibration tires, overload protectors and crankcase heaters to prevent the viscosity of the oil and are provided with direct-start motors cooled by suction gas. These compressors are powered by polyester oil and have IP54 protection.
operator:
The evaporator is a type of stainless steel plate converter, with one or two refrigeration cycles and is highly insulated with high-thickness elastomeric foam and can be UV-coated. The maximum operating pressure is 6 bar water and 42 bar refrigerant. The evaporator is fitted with a flowmeter that turns off the device when the evaporator is running low.
Condenser:
The condenser has copper tubes with aluminum microphones. To increase heat exchange, the design of the filters is based on Turbo-fin technology. The maximum relative pressure of the condenser is 45 bar.
Fan:
High-efficiency direct-coupled direct-current fan features aluminum blades with low noise level and IP54 protection class. They are also fitted with overload protection thermostats and galvanized steel gratings.
Refrigeration Cycle:
Each refrigeration cycle is fitted with disconnecting valve for refrigerant charging, anti-freeze sensor, valve disconnecting valve, site glass, drive filter, high pressure safety valve, thermostatic mechanical expansion valve, and pressure gauges and switches. is.
Electrical board:
Manufacture of electrical boards is in accordance with IEC 204-160204-1 / IEC. Electrical board when installing the device outdoors with a protective cabinet, including control and power system, microprocessor electronic board equipped with keypad and display, main lock-type switch, transformer to separate main circuitry from auxiliary circuits Compressors and fans, protection fuses and switches, alarm terminal and on / off system, board terminal, phase sequence relay and interface to BMS system.
