Addressable fire alarm panel simpo Sarian
Sarian
The SIMPO addressable fire alarm panel has a large LCD display for easy use. This advanced panel has 1 loop and can be increased up to 2 loops, each loop can support 250 addressable pieces. All panel events are displayed on its LCD screen, and there are 16 LEDs on the panel to plan equipment in 96 selected zones. The panel's support for the RS485 protocol is very useful for networking 32 panels over long distances. By connecting the network module to this panel, 32 panel devices can be connected through the network TCP / IP protocol. Panel planning is possible both through the panel keyboard and through the free ProSTE software. Another outstanding feature of this panel is the Modbus output for connecting to the BMS integrated building management system.
You can also make a price as a seller
Request a price to negotiate and get a better offer
Suppliers
| Suppliers | Expiration date | Price (Toman) | Minimum order (MOQ) | City | Phone number |
|---|---|---|---|---|---|
The price is not recorded | |||||
similar products
Addressable fire alarm panel simpo Sarian
Attributes :
It has 1 loop that can be increased up to 2 loops
Supports 250 addressable pieces per loop
It has 16 zones with LED indicator
It has 4 programmable relays 230V / 10A
It has 4 monitored outputs for fire, error and ...
It has 128 inputs and 128 programmable outputs
Record 10,000 events in memory
Has a network port to support 32 network panels with TCP / IP protocol
Ability to support 32 network panels with RS485 module
Ability to add thermal printers
It has a large LCD display with a size of 40/4
Ability to program via computer or LCD display
It has a very easy user interface and User Friendly
With EN54 standard 2/4
Product Specifications
Power supply (V)
230 ± 10%
Dimensions (mm)
441 * 331 * 80
Weight (g)
420
Frequency (Hz)
50-60
Output power (A)
4.7
Operating temperature (° C)
-10 to +50
