MTOPROOF800 flexible bituminous insulation Clinic Beton Iran

MTOPROOF800 is a water-soluble bitumen and rubber-based brown liquid that has excellent adhesion and turns into a hard, black layer after drying.

Basic applications

Water storage tanks and structures: for the waterproofing layer on concrete and brick.

Floors: in order to create a middle layer in new structures.
Walls: on internal and external walls.
Roofs: to repair all types of roofs with gravel, asphalt, lead, zinc, aluminum, concrete, light mortar, board, stone, asbestos, corrugated iron sheets, and as a protective layer against moisture.
As an adhesive: for the installation of wooden flooring parts, insulation boards, expanded polystyrene, cork and also to create a bonding layer for mortar.

Compounds

MTOPROOF800 is made of a combination of cold running bitumen with rubber sap.

packing

MTOPROOF800 is available in 20 and 200 liter containers.

standards

Building Regulations 1972
BS 8102 Protection of structures against ground water
23 DOE Moisture Protection Periods
77 DOE Adhesives used in construction
540 BRE digest Protection of floors against moisture
Physical and chemical characteristics
Specific gravity 1.01 gr/cm3
Dark brown color
Physical state of liquid
Operating temperature -30°C to +100°C
Running time temperature C˚5 to C˚55
Flammability non-flammable
The thickness of the dried layers is 1.16 mm in 2 liters per square meter
The rubber in the composition is 10% in the dried film

Procedure

MTOPROOF800 may be applied with a brush or trowel. All the surface on which MTOPROOF800 is applied must be hard, smooth and free of any dirt, dust, broken pieces, grease, etc. It can be applied on a wet surface, but there should not be visible water, warm surfaces and dry and rough surfaces should be moistened with a primer before applying the main layer of MTOPROOF800. If you need to apply the next layers, it is necessary to dry the previous layer completely.

Protection of underground structures

MTOPROOF800 can be applied immediately after the opening of the mold on fresh concrete. Apply a little clean crushed sand on the applied surface so that the dried layer has more absorbency for applying the next layer.

Multi-layer implementation

Two layers should be applied in the same direction so that the thickness of the dried layer reaches about 770 microns according to BS 8102 standard. The surface of the second layer should be cleaned and roughened using crushed clay to provide a mechanical connection for the application of mortar. (Mortar thickness should be at least 1 mm.)

Wet walls

Scrape off all applied coatings and mortar to reach the brick surface. Apply three layers of MTOPROOF800 and sand the surface of the last layer before it dries.

Apply surface mortars using MTOSIVE1010.

Covering

square meters per liter
Consumption amount, number of layers, first layer, second layer, third layer
- As a primer diluted 6 times with 1 5/7 water
- As a waterproofing layer 2 2 25/2
- Floors as the middle layer.
- Improvement level 2

2 5/1

2 5/1

2
- Internal and external walls 3 25/2 25/2 25/2
- Types of roof coverings
- Vapor control layer 3
2 1
1 5/1
5/1 5/1
- As glue for wood and polystyrene works
- Implementation of layers in difficult levels 1

2 5/1

5/4

5/4

Take care of work tools

Clean the work tool with soap and water before MTOPROOF800 dries, and if it dries, shave it and then clean it with paraffin or petroleum solvent.

safety tips

As with all chemical products, special care should be taken during use and storage. Avoid contact with eyes, mouth, skin and food. In case of splashing on the skin or eyes, clean the area immediately. If accidentally swallowed, you should see a doctor. Close the container after use.

inventory

Store in a covered environment away from sunlight and protect against high temperature. In hot areas, it should be stored in a ventilated environment, as with all bitumen-based materials, some sedimentation occurs in the long term.

Therefore, it is necessary to turn the barrels upside down every week to mix again. The useful life of this product is 6 months, provided that it is stored in the original container and in the right conditions. Failure to comply with the mentioned storage conditions will damage the product or the container.
