MTOTOP107 2-component elastomeric coating Clinic Beton Iran

A two-component modified polymer product and waterproofing mortar slurry with cementitious properties. This product consists of a liquid polymer and a cementitious material, which the combination of these two together creates a special additive that is suitable for use in tropical climates as well as cold conditions. This product has drinking water approval.

Applications of MTOTOP107 2-component elastomeric coating

Applications of MTOTOP 107 2-component elastomeric coating are used in the following cases:

Internal and external sealing and concrete moisture
Cement coating
Brickwork and blockwork
Protection of concrete buildings against the effects of deicing salts and the occurrence of freezing phenomenon
Strong sealing of basement walls in new constructions and renovation of old buildings
Plastering pores and holes
Sealing the basement and cellar (which are not exposed to water pressure)
Fine sealing of hairline cracks in concrete structures (which do not move)
Grout leveling in concrete repair

Properties and effects of 2-component elastomeric coating of MTOTOP107 seal
This product can be easily applied with the help of a brush or trowel
No need for water
This product is packed in packages that have a certain weight
This product can be applied on the surface with the help of a spray
It is easy and quick to mix
It has good adhesion
It protects the concrete from reacting with carbon
Compared to steel and iron, it is not corrosive
It can be used repeatedly on surfaces
It does not lose its properties in contact with drinking water
approvals and standards and has British certificate number 3174/95

Features and specifications of MTOTOP107 2-component elastomeric coating
in the form of loose mortar that can be easily applied with a brush or trowel
Appearance and color
Component A (resin): white liquid
Part B (Harner Beton): gray or white powder
Mixture except A and B: concrete gray or whitish cream

MTOTOP107 waterproof 2-part elastomeric coating packaging

33 kg packages (25 kg bags and 8 kg buckets)

How to store MTOTOP107 2-component elastomeric coating
Maintenance; If it is in its original packaging, it can be kept for at least 6 months after the production date. This material should be stored in a dry and cool place, the liquid part of this product should be protected from freezing.
Technical Specifications
Chemical base
Part A: polymer and liquid additive
Part B: Portland cement, granular materials and special mixes
Density of fresh mortar: approximately 200 kg/liter
Layer thickness
Minimum: 750 mm
Maximum: 15 mm
Thermal expansion of 10 x 13 per degree centigrade
Co2 emission factor u35000
carbon dioxide (uco2)
Emissivity coefficient: uh2o 500
water vapor (uH2o)

Physical mechanical properties of elastomeric coating
pushing resistance
According to EN196-1
3 days approximately 20N/MM2
28 days approximately 35N/MM2
Bending strength
According to EN196-1
3 days approximately 6N/MM2
28 days approximately 10N/MM2
Tensile strength
Dry in water: approximately 3.2N/MM2 after 14 days (according to DIN53455)
Air dry: approximately 4.5N/MM2 after 14 days
Continuity strength 2.0 to 4.5N/MM2 (considered as defect under work)
Static modulus of elasticity: approximately 8.4 KN/MM2

Method and amount of consumption of 2-component elastomeric coating of MTOTOP 107 waterproofing
The amount of use of this product depends on the hardness and appearance of the surface as well
It depends on the thickness of the layer that will be stretched
For example: 2.0 kg/m2 (except when the surface is clean or has pores)
12.05 liters of mortar can be made with a 25 kg package of the product

The quality of the work of the 2-component elastomeric waterproofing coating

- The work surface must be clean and free from pollution and free from airborne particles, cement bubbles, fat and oil
- The tensile strength (adhesion) of concrete should be more than 1.0 N/MM2

How to prepare the work of elastomeric coating
The work surface should be cleaned using suitable mechanical tools such as high pressure water, needle gun, water spray and sandblasting thinner. Before use, the work surface must be wet and then dried
In order to fill pores and holes
All the pollution of the underpass surface should be cleaned
As a leveling mortar
Clean and level all surfaces using mechanical tools, such as sanding, or ensure that all previous contamination and coatings are removed and the pores are ready to be filled. In order to utilize the maximum bond strength, the surface must be clean.

Terms of use of the product
The working temperature is minimum 8 and maximum 35 degrees Celsius
Ambient temperature minimum 8 and maximum 35 degrees Celsius

Instructions for using the product
mix
As a slurry: component A: component B = 4:1 (relative to the weight of the components)
As a mortar: component A: component B = 4.5:1 (relative to the weight of the components)
Mixing time: approximately 3 minutes

Tools required for mixing elastomeric coatings

MTOTOP 107 2-component elastomeric coating must be thoroughly mixed using a mechanical tool such as a stirrer or vane mixer (max. 500 rpm). Normal concrete mixer is not suitable for this work.

Method of use and tools

- Shake component A before use. Pour almost half of the contents of the package of part A into the mixing bowl, and as you stir the mixture, add part B to it. Add the rest of the content of component A to the mixture and stir the mixture until it is a uniform substance without bubbles. The surface must be saturated with water before use.
- As a slurry, MTOTOP 107 can be poured on the surface using a mechanical method, manually and with a dry and stiff brush. The procedure is the same as the previous one.
- When for the second time from MTOTOP 107 2-component elastomeric coating on a

It is used as a base, you have to wait for it to dry with the first coat, then apply the first coat in the same direction using a brush.
- As a mortar: when the 2-component elastomeric coating of MTOTOP 107 waterproofing is poured on the surface using a trowel (in the finishing of a smooth surface), the amount of component A must be 10% less than the mentioned amount (component A 1 and component A B 45) Apply the second coating of MTOTOP 107 2-component elastomeric coating as soon as the surface of the first coating dries. Use a trowel to fill the pores and holes.

Cleaning tools

- Wash all tools and accessories with clean water immediately after use. Hardening materials and agents can be removed using mechanical tools.
- The service life is approximately 30 minutes at a temperature of 20 degrees Celsius
- Waiting time, excellent work coverage
- The waiting time for concrete with two layers of work
- 10°C 12 hours
- 20°C for 6 hours
- 30°C for 3 hours
- If the waiting time exceeds 24 hours, wipe the surface gently
- MTOTOP 107 2-component elastomeric coating can be repeatedly applied to surfaces using solvent-based primers and coatings.
- Before using the 2-component elastomeric coating of MTOTOP 107 as a coating for the second time. You have to wait for 7 days to process it

Notes on product use and limitations
The 2-component elastomeric coating of MTOTOP 107 waterproofing is not a decorative product, and after rain or wetting the surface, signs of (blurry and darkening) of the product may be seen. This does not affect the properties of the coating in any way. If this coating is exposed, it is recommended to use cream-white color, which is a suitable color.
Never place this product under strong sunlight or wind. Draw it on the soft and ready work. The thickness of the layer should not be high.
In order to achieve a thickness of 2.0 to 1.5 mm in sealing or damping, always use two coats. In places that are heavily exposed to water, 3 coats may be needed.
Avoid exposing newly sealed surfaces to rain and freezing conditions.
It should be noted that the surface of the coating is not damaged in the sealing of the dehumidification.
When this product is used in tools that are in contact with the drinking industry.

The performance of the 2-component elastomeric coating of the MTOTOP107 seal

In order to complete the complete process of cement hydration and reduce the occurrence of cracks in the 2-component elastomeric coating, MTOTOP107 must be treated immediately after use for 3 to 5 days. Use the polyethylene coating method with other available methods. All technical information in the product specification sheet is based on laboratory tests. Different results may be obtained by changing the conditions.

Local restrictions

Please note that the terms of use of this product may be different in different countries due to local laws.
