Thermal detector Ariak

Ariak Electric Co., with the approval of the Fire Department of Iran, started producing fire alarm accessories and products from 1996 until now. The company has obtained the standard certification of products from the Iranian Institute of Standards and Industrial Research in 2009. Enjoying specialized and equipped labs and working with experienced engineers, sophisticated design with up-to-date technology and in line with European and national accredited professional standards, focusing on satisfying customers is the familiar feature of Ariak products. In the following, it will be shown that the price of the Ariak incremental thermal detector seems to be very economical compared to the services that offer these services which reduce the losses and casualties.

Incremental Thermal Detector Specifications:
Ariaac fire alarm thermal detectors such as thermostats have a heat-sensitive electrical or mechanical part. Regardless of whether the incremental thermal detector sensor is of a thermal, electrical or mechanical type, the detector performs an electrical process and sends a message to the control center as well. Depending on what conditions and how they are used, thermal detectors must have special capabilities and structures that could be another distinction for their classification. Ability to use in high humidity conditions, impermeable to dust, and the specificity of application in explosive hazardous areas are some of the factors that can cause variations in the structure. The grouping of detectors is also based on the temperature at which they are activated. According to this grouping, temperatures range from 57 to 60 degrees Celsius, temperatures between 65 to 70 degrees Celsius and 90 degrees Celsius.
In general, the IR incremental thermal detector is not suitable for spaces over 9 m high and the constant temperature thermal detector is not recommended for spaces over 5.7 m high.

Installation height: 6 to 9 meters (in most models the maximum installation height is less than 7 meters)
Covered Area: From 10 to 50 square meters depending on the type of sensor (it is true that the space covered by each thermal detector based on its trademark will be extracted from the manufacturers' catalogs and technical documentation and based on the design).
Reaction to Hidden Fires: Bad
Rapid Fire Reaction: Okay
Thermal detector: (6 meters at 5.2 meters), (5.5 meters at 4 meters), (5 meters at 6 meters)
Usage: Kitchens, motorcycles, parking lots, and places where the use of Ariac smoke detectors are not possible due to steam or smoke from the natural mechanism of equipment or activities.
Ariac incremental thermal detector

This detector is suitable for detecting high-flame and exothermic fires and is recommended for use in places where, in the normal state, sudden changes in ambient temperature occur. You also get the following installation guide by purchasing an Ariac incremental thermal detector:

Center zone terminals must be connected to detector pins 1 and 6 (base positive 1 and base negative 2)
When the detector is mounted on the stand, the supply voltage is set at terminals 2 and 5, which must be connected to the stands 1 and 6 of the next detector or end-of-line resistor (EOLR).
Remote lamp output (headlamp) should be taken from Grades 3 and 4 (Grade 3 positive and Grade 4 negative). This light is illuminated by the action of the detector.
In order for a remote light to command multiple detectors, the base number 4 of those detectors must be connected to each other.
It should be noted that Alborz Insurance will be liable for two years if the Alborz Insurance Company is liable for damages.
