Duct Split GDS-36P1T1A Green ac

Green ac
Iran

In general, duct splits or channel splits are among the most common air conditioning systems in the world, which, like wall splits, are composed of indoor and outdoor units. Internal and external units are connected by copper pipes and provide cooling and heating of the desired space.
Duct splits are usually installed on the false ceiling of office and residential buildings and provide cool air in summer and warm air in winter for all spaces in an apartment unit and transfer hot or cold air by ducts running inside the false ceiling. , Brings the desired ambient temperature to the desired comfort and setting conditions of the thermostat.
Green GREEN Air Conditioning Company is one of the most successful manufacturers of air conditioning systems, including Duct Split, which relies on modern European technical knowledge, experienced specialists as well as advanced fully automatic machines and equipment, quality products and in line with the highest guarantee standards. Produces quality in Europe.
Split Green Duct is produced in different types of four-way and built-in shortcomings in capacities of 1.5 to 5 tons of refrigeration. Also, Green Duct split ducts for temperate or tropical regions using R410a and R22 refrigerant gas have been offered in two different types of on-off and inverter type.
The R22 Green downtime split duct, with a static pressure of 50 to 80 Pascals, uses R22 refrigerant gas and a Twin Rotary compressor and has a Grade B energy rating. This split duct Green model is produced in 2, 3 and 4 tons refrigeration capacity.
You can also make a price as a seller
Request a price to negotiate and get a better offer

Suppliers

SuppliersExpiration datePrice (Toman)Minimum order (MOQ)CityPhone number
The price is not recorded

similar products

Duct Split GDS-36P1T1A Green ac

Attributes : Beautiful and modern design suitable for different architectural stylesQuiet and quiet operationIt has a suitable height for installationStatic pressure 50 to 80 PascalHitachi Twin Rotary Design CompressorIt has a drain pump with a pumping opening of 1200 mmEquipped with wall thermostat with digital displayThree-phase 380V three-phase power consumptionFull temperature range for different climates from -10 to +55 degrees CelsiusAbility to connect to fresh airAbility to change the air intake valveEquipped with filter to increase air quality

Product Specifications

Internal panel installation position
Defective ceiling
Operating conditions
Tropical
Air circulation (m3 / h)
1500/1200/1050
External static pressure (Pa)
50/80
Cooling capacity (BTU / h)
36000
Heating capacity (BTU / h)
37500
Cooling capacity (tons)
3
Heating / Cooling Current (Amp)
16.3 / 17
Indoor unit sound level (Db)
39/45/48
Dimensions of outdoor unit (mm)
903x857x354
Indoor unit weight (Kg)
24
External unit weight (Kg)
86
Compressor type
Rotary
Inverter kit (low consumption)
does not have
Refrigerant gas
R22
Liquid tube size (inch)
8-Mar
Gas pipe size (back) (inch)
08-May
Drain diameter (inch)
04-Mar
Maximum piping length (m)
40
Maximum piping height (m)
15
Operating temperature range (c)
Oct-55

ابعاد یونیت داخلی (mm)

Body
835x835x250
the frame
950x950x55
